360° Multi-flash Signal Lamp

Multi-purpose All round signal lamps with programmable flash modes and synchronization options. Optics appear clear until illuminated.



SKU: 360° Multi-flash Signal Lamp Categories: , , Tags: ,

Multi-purpose signal lamps with robust housings, 10 programmable flash modes and the ability to be synchronised to flash alternately or in unison. Optics appear clear until illuminated.

Each lamp is a completely sealed unit. Proven design, precision engineering and the use of high impact acrylic materials ensure superior resistance to water, impact, UV and wear and tear. Advanced Multivolt™ circuitry provides reliable illumination across a range of DC inputs from 9-33 volts, even during low battery voltages, and voltage drop over long cable runs.

Material Description Ultra heavy duty Grilamid® lens
Cable 2.5m of multi core cable
Operating Voltage Multivolt™ 9-33V DC
Voltage Protection Spike protected to +500 volts
Power Consumption <5W (<0.42A@12V / <0.021A@24V (Continuously on) Less in flash modes
Degree of Protection IP 67 – Completely Sealed
Weight 150g (including cable)
Approvals CE

Description

Documents

DownloadDocument NameCategoriesTagsSizeTypehf:doc_categorieshf:doc_tags
Multi-Flash Signal, Drawing, , , , 33 KBpdfinterior diagram-drawing2xd-980-911-002 2xd-980-911-202 2xd-980-911-402 2xd-980-911-602 2xd-980-911-702
Multi-Flash Signal, Instructions, , , , 470 KBpdfinterior-instructions-sheets instructions-sheets2xd-980-911-002 2xd-980-911-202 2xd-980-911-402 2xd-980-911-602 2xd-980-911-702
